These industrial ICP accelerometers have ceramic sensing element of annular shear design in a top-exit, heretically sealed, stainless steel housing. All of our accelerometers are case isolated and provide excellent resolution and durability in noisy industrial environments.
Low Cost Single Axis Accelerometer (SQI608A11-3F)
  • Low-cost, general purpose, industrial ceramic shear ICP accel, 100mV/g, 0.5 to 10k Hz, top exit, 10-ft integral cable
  • Sensitivity: ( ±15%) 100 mV/g (10.2 mV/(m/s²))
  • Frequency Range: (±3dB) 30 to 600000 cpm (0.5 to 10000 Hz)
  • Measurement Range: ±50 g (±490 m/s²)
  • Mounting: Stud
  • Electrical Connector: 10′ long cable to BNC connector
  • Also comes in 4 pack and 8 pack
  • Come with 3′ long cable with transducer to BNC connector and 7′ BNC-BNC extension cable
Low Cost Single Axis Accelerometer (SQI608A11-10F)
  • Low-cost, general purpose, industrial ceramic shear ICP accel, 100mV/g, 0.5 to 10k Hz, top exit, 10-ft integral cable
  • Sensitivity: ( ±15%) 100 mV/g (10.2 mV/(m/s²))
  • Frequency Range: (±3dB) 30 to 600000 cpm (0.5 to 10000 Hz)
  • Measurement Range: ±50 g (±490 m/s²)
  • Mounting: Stud
  • Electrical Connector: 10′ long cable to BNC connector
  • Also comes in 4 pack and 8 pack
  • Come with 10′ long cable with BNC connector
Tri-Axis Accelerometer (SQI604B31)
  • Triaxial ring-style, industrial, ceramic shear ICP accel, 100 mV/g, 0.5 to 5k Hz, side exit, 4-pin conn.
  • Sensitivity: (±20%) 100 mV/g (10.2 mV/(m/s²))
  • Frequency Range: (±3dB) 30 to 300000 cpm (0.5 to 5000 Hz)
  • Measurement Range: ±50 g (±490 m/s²)
  • Mounting: Through Hole
  • Electrical Connector: 4-Pin MIL-C-26482 and 10′ long cable to three BNC connectors
Accelerometer Mounting Kit (M-AMK)
  • Attach your accelerometer (¼ – 28 thread) to your machinery
  • The kit consists of 6 disks, 2 magnets and adhesives
Triaxial accelerometer mounting block (M-TAMB)
  • Convenient, inexpensive, triaxial measurements. It provides a means to secure three transducers (¼ – 28 thread) in an X-Y-Z configuration in a compact arrangement.
  • The kit consists of one triaxial mounting block
